There is no single “U.S. flame-retardant test” for every textile. A clothing fabric, children’s pajama, industrial workwear garment, sofa cover, mattress barrier and vehicle headliner may use different ignition sources, specimen orientations, measurements and compliance systems.

ASTM D6413 vertical-flame results cannot replace the 45-degree apparel test in Part 1610 or the horizontal automotive test in FMVSS 302. Coating, foam, adhesive and backing can also change the applicable configuration and result.

Understanding U.S. Flammability Regulations and Test Standards

Regulation vs. Test Method vs. Certification

A federal regulation creates legal requirements for in-scope products. A consensus standard defines technical requirements and may support purchasing or certification programs. A test method explains how a specimen is exposed and measured.

A laboratory report records results. Certification connects a defined product to a conformity scheme, documentation and labeling. Buyers should ask what evidence is required—not simply request “the American FR certificate.”

Fabric Test Results vs. Finished-Product Compliance

Evaluation may concern a specimen, component, garment, mattress set or vehicle. Seams, foam, adhesive, laminates, care cycles and exposed surfaces can affect finished-product performance.

16 CFR Part 1610: General Clothing Textiles

Product Scope

16 CFR Part 1610 is the federal Standard for the Flammability of Clothing Textiles. It applies to textiles intended for wearing apparel, subject to stated exclusions and testing exemptions. Its purpose is to keep dangerously flammable clothing textiles out of U.S. commerce.

45-Degree Flammability Test

The specimen is mounted at a 45-degree angle in the specified apparatus. The procedure records flame-spread time and burning behavior. Requirements differ for plain-surface and raised-surface fabrics because a fuzzy surface flash may behave differently from ignition of the base fabric.

Flammability Classes

Part 1610 establishes three classes:

• Class 1: normal flammability and acceptable for clothing.

• Class 2: intermediate flammability; applies only to raised-surface fabrics and may be used with caution.

• Class 3: rapid and intense burning; dangerously flammable and prohibited for wearing apparel.

Classification depends on surface type, burn time and observed behavior; one informal time limit cannot be applied to every construction.

What Passing Part 1610 Does Not Mean

Part 1610 is a general clothing-flammability requirement. A Class 1 result does not prove that a fabric is flame resistant for industrial flash fire, arc rated for electrical work or suitable for automotive interiors.

16 CFR Parts 1615 and 1616: Children’s Sleepwear

Applicable Sizes and Product Scope

Part 1615 covers children’s sleepwear in sizes 0 through 6X; Part 1616 covers sizes 7 through 14. CPSC considers product design, dimensions, intended sleeping use, labeling and marketing when determining scope.

Vertical Flame Testing

In-scope sleepwear uses a vertical small-open-flame procedure in which char length is a central measurement.

Fabric, Seam, Trim and Garment Requirements

Requirements cover fabric and garment production units, including seams, trims, production garments, records and labeling. A fabric report alone is incomplete evidence.

Tight-Fitting Sleepwear Exceptions

Defined infant garments and sleepwear meeting the exact tight-fitting dimensions are excepted from the sleepwear flame-resistance testing provisions and generally follow Part 1610 instead. “Tight fitting” is a regulatory definition, not a marketing description.

ASTM D6413/D6413M: Vertical Flame Test for Textiles

Test Procedure

ASTM D6413/D6413M evaluates a textile specimen held vertically in a draft-free test area and exposed to a specified ignition source for a defined time. The method is widely referenced in protective-textile specifications.

Afterflame, Afterglow and Char Length

The method reports afterflame, afterglow and char length. Results depend on specimen preparation, conditioning and required durability exposure.

Why ASTM D6413 Is Not a Certification

ASTM D6413 does not provide one universal pass/fail limit for every textile application. ASTM also cautions that controlled laboratory results should not be used alone to describe actual fire risk. A buyer must identify the product standard or contract that supplies acceptance criteria.

NFPA 2112: Industrial Flash-Fire Protective Clothing

Applicable Hazards and Products

NFPA 2112 addresses flame-resistant garments and specified protective items for industrial personnel exposed to short-duration thermal exposure from fire. It is commonly associated with oil, gas, petrochemical and other workplaces where flash-fire hazards are assessed.

Fabric and Garment Performance

It includes material and garment requirements for thermal performance, heat resistance, construction and labeling. Confirm the edition and certification program before development.

Third-Party Certification

NFPA 2112 contains certification provisions. A report for one fabric test is not equivalent to an NFPA 2112-certified garment. Buyers should state whether they need certified material or components, a certified finished garment, or development test data.

NFPA 70E: Electrical Workplace Safety

Flame-Resistant vs. Arc-Rated Clothing

NFPA 70E supports electrical risk assessment, safe work practices and selection of arc-flash PPE. Flame-resistant clothing without an arc rating has not necessarily been evaluated for electric-arc exposure. Arc-rated clothing is flame resistant, but not all flame-resistant clothing is arc rated.

Why NFPA 70E Is Not a Fabric Certification

NFPA 70E is a workplace electrical-safety standard, not a fabric certificate. The employer’s hazard assessment determines the protection needed. Clothing and materials then require the appropriate product specifications and arc-rating evidence.

ASTM F1506: FR and Arc-Rated Protective Clothing

Material Performance Requirements

ASTM F1506 is a performance specification for flame-resistant and electric-arc-rated protective clothing. It addresses minimum requirements for fabrics, subassemblies and garments, including FR performance, arc rating, mechanical durability, construction and labeling.

Arc Rating and Durability

Arc rating uses referenced arc-test methods; FR and physical properties follow other specified conditions. Conditioning and laundering requirements also matter.

Information Buyers Must Specify

An inquiry should identify the ASTM F1506 edition, required arc rating, fabric weight, construction, color, care route and any additional employer or utility requirements. “F1506 fabric” alone is not a complete specification.

16 CFR Part 1640 and TB 117-2013: Upholstered Furniture

Smolder-Resistance Testing

16 CFR Part 1640 is the federal upholstered-furniture flammability regulation. It incorporates the specified 2013 version of California TB 117, which addresses smoldering ignition rather than a general open-flame fabric test.

Components Covered

Tests address cover materials, barriers, resilient filling and decking. The applicable furniture construction matters more than an “FR” label on the outer fabric.

Flame-Retardant Chemicals Are Not Automatically Required

CPSC guidance states that Part 1640 has no chemical-composition requirement. Materials with or without added flame-retardant chemicals may meet the tests. The regulation neither universally requires nor universally prohibits those chemicals.

16 CFR Parts 1632 and 1633: Mattresses

Part 1632 Cigarette-Ignition Test

Part 1632 addresses smoldering ignition resistance of mattresses and mattress pads when exposed to a lighted cigarette under defined conditions.

Part 1633 Open-Flame Test

Part 1633 addresses mattress sets exposed to an open-flame ignition source and limits fire size during a 30-minute test. The two regulations address different ignition scenarios.

Why Individual Fabric Testing Is Not Enough

Ticking, barriers, filling and seams interact during exposure. One textile report does not establish compliance of every mattress design.

FMVSS No. 302 / 49 CFR §571.302: Automotive Interiors

Covered Vehicle Components

FMVSS No. 302 specifies burn-resistance requirements for listed occupant-compartment materials in passenger cars, multipurpose passenger vehicles, trucks and buses. Covered examples include seat cushions and backs, seat belts, headlining, convertible tops, armrests, trim panels, compartment shelves, head restraints, floor coverings, sun visors, curtains and shades.

Applicability depends on component listing, material location and proximity to occupant-compartment air space.

Horizontal Burn-Test Procedure

Unlike the 45-degree apparel test or ASTM D6413 vertical test, FMVSS 302 uses a horizontal specimen configuration. A flame is applied at the open end, and flame-front travel is timed between defined reference points. Testing is conducted in the standard’s specified chamber and specimen arrangement.

ASTM D6413 cannot replace FMVSS 302 because melting, curling and flame travel can change with specimen orientation.

Maximum Burn-Rate Requirement

Under S4.3, applicable material tested according to S5 must not burn or transmit a flame front across its surface faster than 4 inches per minute, equivalent to approximately 102 mm/min. The standard also contains a provision for material that stops burning within the specified time and travel distance.

The 4 in/min figure should therefore be cited with the test procedure and detailed provisions—not treated as a free-standing requirement for any sample size or laboratory setup.

Composite Materials and Test Orientation

Automotive textiles are often laminated to foam, scrim or backing. FMVSS 302 distinguishes materials that adhere at every point of contact from those with nonadhering interfaces, affecting whether they are tested as a composite or separately under the standard.

Surface orientation also matters. The surface closest to occupant-compartment air space is positioned as specified in the test frame. A decorative face fabric tested alone may not represent the production laminate with foam and adhesive.

For meaningful development, the buyer should send the laboratory the production-equivalent component stack: face material, coating, adhesive, foam, scrim and backing, with layer thicknesses and intended exposed surface clearly identified.

Manufacturer Self-Certification

NHTSA’s FMVSS 302 procedure explains the agency’s compliance-test approach. NHTSA does not pre-approve an individual roll of fabric. Applicable vehicle and equipment manufacturers are responsible for certifying that their products meet relevant federal motor-vehicle safety standards.

A supplier report can provide evidence for a material or component configuration, but it does not certify the complete vehicle or guarantee all colors, thicknesses, backings and production lots.

Comparison Table of U.S. Flammability Standards

What Buyers Should Provide Before Testing

• Finished product and exact component name

• Target U.S. market, customer and jurisdiction

• Regulation or standard and required edition

• Fiber content, construction, weight and thickness

• Coating, lamination, foam, adhesive and backing details

• Intended exposed surface and test orientation

• Conditioning, washing or durability requirements

• Acceptance criteria and required report format

• Required laboratory accreditation or customer approval

• Whether evidence is for fabric, component, garment or finished product

Relevant product pages can later be linked as [automotive interior fabric — internal link], [flame-resistant fabric — internal link] and [custom testing and textile development — internal link].

Frequently Asked Questions

Is ASTM D6413 a Certification?

No. It is a vertical flame test method. Acceptance criteria and certification, if required, come from another standard or program.

Does Passing 16 CFR Part 1610 Mean a Textile Is Flame Resistant?

No. It demonstrates classification under the general clothing regulation, not flash-fire, arc-flash or automotive performance.

Can ASTM D6413 Replace FMVSS 302?

No. The specimen orientation, procedure, measurements and intended application differ. Automotive components should be evaluated under the applicable FMVSS 302 configuration.

Is the FMVSS 302 Limit Always Stated as 4 Inches per Minute?

Four inches per minute is the commonly cited maximum flame-front rate under S4.3, but the complete standard includes defined specimen, procedure and self-extinguishing provisions. Use the current regulatory text.

Does an FMVSS 302 Fabric Report Certify the Vehicle?

No. It documents the tested configuration. The responsible manufacturer handles vehicle or equipment self-certification.

Are NFPA 2112 and NFPA 70E Interchangeable?

No. NFPA 2112 addresses industrial short-duration thermal exposure from fire; NFPA 70E addresses electrical workplace safety and arc-flash PPE selection.

Does TB 117-2013 Require Added Flame-Retardant Chemicals?

No. The federal Part 1640 framework does not impose a chemical-composition requirement.

Choose the Correct Standard Before Ordering Fabric

Start with the finished product and hazard, then identify the regulation or standard, production configuration, test method, acceptance criteria and documentation route. This sequence prevents a vertical textile test from being incorrectly used for apparel, furniture or automotive compliance.

Send us the end use, target standard, construction, weight, coating or laminate details and required evidence. We can help prepare a development specification and sampling plan. Final compliance and certification decisions should be confirmed by the responsible manufacturer, importer, qualified laboratory, certification body or compliance professional.
