1680D Flame-Retardant Polyester Ballistic Fabric with Pvc coated

1680D Flame-Retardant Polyester Ballistic Fabric

1680D Flame-Retardant Polyester Heavy-Duty Fabric with PVC Coating

Custom woven polyester fabric for industrial covers, reinforced bags, equipment enclosures and heavy-duty outdoor use. Typical finished weight 650-900 gsm, with flame-retardant and PVC coating options developed to the buyer's end-use requirements.


Availability:



Inquire Add to Basket

Model:
KIGI-FR-PET-1680D-HEAVYDUTY-PVC
Brand:
KIGI Textile
Code:
FRPET-012

This 1680D FR heavy-duty polyester is a custom woven fabric for B2B programs that need high durability, PVC waterproofing and flame-retardant performance in one construction. It is commonly specified for industrial covers, reinforced bags, equipment enclosures, outdoor shelters and other heavy-duty outdoor or industrial components.

Key specs (typical; confirm before sampling)

• Yarn count: 1680D × 1680D

• Base: 100% recycled polyester (rPET)

• Type: Heavy-duty woven fabric

• Finish: PVC coating + flame-retardant treatment

• Typical finished weight: about 750gsm (customizable approx. 650–900gsm)

• Width: 57/58" (other widths on request)

• Supply type: Make-to-Order

Why buyers choose 1680D FR heavy-duty PVC

• Heavier coated body than PU ballistic programs for tougher cover and enclosure use

• PVC coating supports strong waterproofing for outdoor and industrial end uses

• High abrasion and tear resistance for reinforced bags and equipment covers

• FR finish can be developed to the buyer’s target test method and acceptance criteria

• Color, coating build, hand feel and water-resistance target are adjustable

Typical applications

• Industrial covers and equipment enclosures

• Reinforced bags and heavy-duty luggage panels

• Outdoor shelters and event / storage covers (when FR is required)

• Fire-resistant tool bags and equipment bags

• Heavy-duty outdoor components exposed to rain and abrasion

Before bulk production

Please confirm: target FR standard/test method, hydrostatic-pressure target, color (lab dip), usable width, PVC coating build and packaging. Final compliance depends on the exact yarn, density, color, coating and finish of the production lot.

Model: KIGI-FR-PET-1680D-HEAVYDUTY-PVC | Code: FRPET-012 | Brand: KIGI Textile

FAQ — 1680D Flame-Retardant Polyester Heavy-Duty Fabric with PVC Coating

Q1. What is 1680D polyester heavy-duty fabric with PVC coating?

A1. It is a heavy woven polyester fabric finished with PVC coating and flame-retardant treatment. Compared with lighter Oxford or PU ballistic constructions, it usually offers a heavier coated body for industrial covers, reinforced bags and equipment enclosures.

Q2. What is the hydrostatic head / waterproof rating?

A2. With PVC coating, water resistance is customizable. Common buyer targets for outdoor covers and industrial enclosures are around ≥ 8000 mmH₂O or ≥ 10000 mmH₂O, depending on coating build. Please confirm your target hydrostatic pressure before sampling.

Q3. Is this fabric made from recycled polyester? Do you have GRS certification?

A3. Yes. The base fabric is 100% recycled polyester (rPET). GRS documentation can be discussed according to the confirmed construction and order requirements.

Q4. What are the typical applications?

• Industrial covers and equipment enclosures

• Reinforced bags and heavy-duty luggage panels

• Outdoor shelters and event / storage covers (when FR is required)

• Fire-resistant tool bags and equipment bags

• Heavy-duty outdoor components exposed to rain and abrasion

Q5. Which flame-retardant standards can this fabric be tested to?

A5. Testing may be arranged according to ASTM D6413/D6413M, CPAI-84, NFPA 701 or another customer-specified method, depending on the end use. Final compliance must be verified on the exact color, PVC coating and construction ordered. These methods are not interchangeable.

Q6. How do I verify flame-retardant performance before a bulk order?

A6. We can support:

• Existing test-report reference (when available for a comparable construction)

• Small sample / yardage for your own lab testing

• Third-party pre-shipment inspection on the agreed production lot

Please confirm the target standard/method first.

Q7. What is the typical weight and width?

A7. Typical finished weight is about 750gsm (customizable approx. 650–900gsm). Standard width is 57/58"; other widths can be discussed.

Q8. How is this different from 1680D ballistic fabric with PU coating?

A8. This heavy-duty PVC version is usually heavier and more cover/enclosure oriented. The 1680D ballistic PU version is more often used for premium luggage, tool bags and abrasion-prone panels with a lighter coated hand. Choose based on end use, hand feel and waterproof target.

Q9. Are swatch samples free?

A9. Swatch / A4 / hanger samples are usually free. International shipping is paid by the customer.

Q10. What are MOQ, lead time and payment terms?

A10. Usual MOQ depends on the confirmed construction and colorway (often discussed from about 1000m/color). Bulk lead time is commonly about 15–20 days after first-lot confirmation. Payment: TT / L/C.
